Unbreakable folding handle left

Unbreakable folding brake handle, marked in the name as left. The photo marks two figures: 142 mm from the lever's ball end to the rear corner of the housing, and "D 22" at the clamp bore.

• The 142 mm arrow rests against the lever's ball end at one end and the housing's rear corner at the other — that is the lever together with the housing. The ribbed cable end and the clamp bolts sit beyond the arrow, so the whole assembly is about 38 mm longer
• The "D 22" arrow rests against the round clamp bore: a clamp like this fits on a 22 mm handlebar
• The clamp bore is the first figure to match: a clamp that does not fit the handlebar either will not tighten or will not go on at all
• The photo shows a folding hinge with a silver bolt — this is why the handle is called unbreakable: on a fall, the lever folds instead of breaking
• The photo also shows a ribbed cable adjuster and an adjusting bolt with a lock nut
• The other half of the pair is a separate product — "Unbreakable folding handle right". Do not compare the figures directly: there, 160 mm measures the whole part, while here 142 mm measures only up to the rear corner of the housing
• A cable handle and a hydraulic one look alike from the outside but differ inside: a steel cable hooks onto the cable version, a hose screws onto the hydraulic one. Check what comes off your old one
• Time to replace it when the lever is bent, when the pivot pin is loose, or when the clamp ear is cracked at the bolt
• Some brake handles in the shop sit not in this category but in "Levers / Knobs" — if you do not find a match here, open that category in the catalogue
• This category holds different products: single handles, pairs of them, switch assemblies and master cylinders. This is not one set

To be straight with you: whether the handle is cable or hydraulic is not stated in the name; the photo shows the cable adjuster, but no hose connection point is visible. Which specific model and which years this product fits, the maker did not state, and we do not guess — but we can compare dimensions: write us your model and year. Before ordering, measure your handlebar diameter at the clamp and the lever length from the pivot to the tip — or send us a photo: we will check it before you order.

24-month warranty · tel. +370 685 777 56
